CNC Machining Case
Studies and Project Examples
Explore CNC machining case studies for custom machined parts, materials,
processes, surface finishes, and application scenarios we support.
Custom CNC Machining Case Studies
Aluminum Housing for Automation Equipment
Custom milled housing designed for assembly accuracy and stable equipment installation.
Material: 6061-T6 Aluminum
Process: CNC Milling
Finish: Clear Anodized
Industry: Automation
Stainless Steel Shaft for Medical Device
Precision turned shaft with smooth surface finish and controlled dimensional accuracy.
Material: 316L Stainless Steel
Process: CNC Turning
Finish: Passivation
Industry: Medical Device
Black Anodized Bracket for Robotics
Lightweight aluminum bracket with black anodized finish for robotic assembly applications.
Material: 6061-T6 Aluminum
Process: CNC Milling
Finish: Black Anodized
Industry: Robotics
5-Axis Aluminum Impeller Prototype
Complex prototype part machined with multi-axis toolpaths for curved blade geometry.
Material: Aluminum 7075-T6
Process: 5-Axis CNC Machining
Finish: Bead Blasted
Industry: Aerospace / Fluid Equipment
Brass Precision Connector
CNC turned brass connector with plated finish for reliable industrial connection use.
Material: C360 Brass
Process: CNC Turning
Finish: Nickel Plated
Industry: Industrial Control
Rapid Prototype Fixture
Custom fixture prototype produced for part positioning, testing, and production validation.
Material: 6061-T6 Aluminum
Process: CNC Milling
Finish: Clear Anodized
Industry: Rapid Prototyping
Before shipment, project parts can be checked according to customer drawings and common quality management standards.
Have a Similar CNC Machining Project?
Send us your drawings, material, quantity, tolerance, and finishing requirements. Our engineering team will review your project and provide a fast quote.
